Working Pressure |
0.5~2.0 bar |
|
Maxminum pressure |
3.0 bar |
|
Supply voltages |
10.8~14.4V (Comon DC12V) |
|
Inlet gas fitting |
φ10mm, φ12 mm, φ14mm, φ16mm |
|
Outlet gas fitting |
Calibrated nozzles M8x1 |
|
Calibrated hole range |
1.0~2.75 mm (0.25 mm step) |
|
Temperature range for LPG |
-20 ~120°C |
|
Temperature range for CNG |
-40 ~120°C |
|
Openning time |
2.5ms, 2.8ms, 3.2ms |
|
Closing time |
1.9ms |
|
Resistance |
3Ω |
